GLZ-RP-0011200 x 1000 x 150 mm
Grid Plastic Pallet
Static Load4,000 kg
Pallet Series1 / 4Category LineRackable Plastic Pallet
Browse All →GLZ-RP-004Rackable Plastic PalletBrand New
PP Pallet
It is universally applicable in closed circuits, production plants, and goods distribution. The high impact strength of this plastic pallet significantly reduces the risk of damage with such improper handling, and thus extends the service life. It’s easy to clean after use and is mainly used for warehouse stacking with a high load.
Static Load4,000 kgISO 8611 verified
Dynamic Forklift1,500 kg4-way forklift / pallet jack
Racking Beam1,000 kgSelective AS/RS beam
Technical Specifications SheetISO / ASTM Compliant
Nominal Dimensions1200 x 1000 x 150 mm
Polymer Material100% Virgin HDPE
Forklift Entry4-Way Forklift Entry
Surface ProfileVentilated Grid Deck
Base Construction3-Runner Chuanzi Base
Standard ColorIndustrial Blue / Safety Yellow
Procurement & Volume Quotation
Select order quantity to request an official company quotation or speak with engineering.
Model Variations & Dimensional Matrix
Factory dimensional tolerances and model configurations for PP Pallet.
| Type: | Vented deck |
|---|---|
| Style: | Single faced |
| Material: | HDPE |
| forklift: | OK |
| Dimension(mm) | Load Capacity(KGS) | QTY/Container | ||||||
|---|---|---|---|---|---|---|---|---|
| L | W | H | Dynamic | Static | Racking | 20' GP | 40'GP | 40'HQ |
| 1200 | 1000 | 150 | 1.5T | 6T | 1.2T | 214 pcs | / | 508 pcs |
Engineering & Structural Architecture
It is universally applicable in closed circuits, production plants, and goods distribution. The high impact strength of this plastic pallet significantly reduces the risk of damage with such improper handling, and thus extends the service life. It’s easy to clean after use and is mainly used for warehouse stacking with a high load.
01
Overview
Q: How can I know which pallet suits my use?
A: We suggest to check below details and contact our sales team to get a prompt and professional solution,
1. Pallet application,
For stack-generally choose double-faced pallets and full perimeter bottom type pallets;
For racks-generally choose 3 runners pallets, full perimeter bottom type pallets, and double-faced pallets;
For transportation-generally choose 3 runners pallets, full perimeter bottom type pallets, and 9 feet pallets;
For one-way delivery-generally choose 9 feet pallets.
2. Pallet size,
3. Pallet load capacity: dynamic load, static load, and racking load.
Q: Can you make any color pallets?
A: Yes, we can customize it for any color.
Q: What’s the MOQ?
A: No MOQ.
Q: How long for the delivery time?
A: Generally 15-20days against the deposit.
Q: Any other additional service you can provide?
1. Customized Logo printing;
2. Customized color;
3. Free det+dem at destination port;
4. Three years quality warranty.
Q: Can it be printed?
A: Can be printed, logo, silkscreen, and mold printing.
Q: Is there any quality assurance?
A: Quality Warranty 3 years. 1 for 1 within 1 year, 2 for 1 within 2 years, 3 for 1 within 3 years. And support 3rd party tests.
Core Structural Highlights
Recommended Applications
